The CZKJ-1010 is a 10.525G radar sensor with configurable power modes launched by Jingchuang Heli. Its typical power consumption is approximately 27 mA,
and in low-power mode, it can drop to as low as approximately 55 µA. The module measures 10 mm × 10 mm, and the sensor utilizes the high-end radar sensing chip AT10LP1T1RDB.
This chip fully integrates a 10.525 GHz microwave circuit, an intermediate frequency (IF) amplifier circuit, and a signal processor. It features high integration and excellent manufacturing consistency. Paired with a miniaturized planar antenna, it ensures sensor performance while significantly reducing the overall size. Due to its low power consumption, exceptional cost-effectiveness, and ability to easily pass RF certification, this sensor is widely applicable in fields such as battery-powered lighting and camera wake-up functions.
